Get the most out of your pool heating investment!
- High performance titanium heat exchanger
- Microprocessor controlled defrost cycle allows operation down to mid to low 40s F
- Built-in drain pan for condensate management
- Impact resistant, rust and fade proof cabinet
- Quieter than conventional heat pumps
- NEW Smart Microprocessor Control
- Weather protected microprocessor control with water temperature setpoint dial (60-104 F), easy to use and compatible with most external controllers
- Flip-out, lockable control panel is protected against sun and weather and can be easily programmed to prevent others from tampering with settings
- Ability to connect to most external controllers
- Rated in accordance with AHRI standard 1160.
Now you can control your heat pump right through your smartphone. Adjust your temperature setting in the PoolSync app.
*Additional purchase of PoolSync WiFi Controller required
Specifications
| BTUs (water temp/ambient air/relative humidity) |
T55 |
| 80/80/80 | 52,000 |
| 80/80/63 | 50,000 |
| 80/50/63 | 33,000 |
|
Coefficient of Performance
(water temp/ambient air/relative humidity) |
|
| 80/80/80 | 6 |
| 80/80/63 | 5.8 |
| 80/50/63 | 4 |
| Refrigerant | R410A |
| Heat Exchanger | Tube in Tube |
| Electrical | |
| kW Input | 2.7 |
| Voltage/Hz/Phase | 208-230/60/1 |
| Minimum Circuit Ampacity | 22.6 |
| Maximum Fuse Size | 30 |
| * Over Temperature Alarm Kit available: part number STK0221 for single phase, STK0222 for three phase. Strongly recommended for all spa applications. | |
| Water Flow | |
| Minimum/Maximum (gpm) | 20/45 |
| * A Heater Bypass Kit is required when flow rates exceed the maximum: part number STK0135. | |
| Physical | |
| Weight (lbs) | 196 |
| Length x Width x Height (in) | 34″ x 34″x 28″ |
| Shipping | |
| Weight (lbs) | 236 |
| Length x Width x Height (in) | 37″ x 36″x 34″ |
Rated in accordance with AHRI standard 1160 water temp/ambient air/relative humidity.
Brochure & Manual
AquaCal TropiCal T55 Heat Pump Brochure
